Features
> Third-party network cameras supported
> Up to 5MP video recording
> HDMI and VGA output up to 1920×1080P resolution
> 4/8 independent PoE network interfaces
> Plug & Play automatic installation and configuration
> 2 SATA HDD interface up to 4TB each
Specifications
|
Model |
VT-7604N-4P |
|
Main Processor |
-- |
|
Operating System |
Embedded Linux |
|
System Resources |
Pentaplex function: live, recording, playback, backup & remote access |
|
Control Mode |
Front panel, USB mouse, Network |
|
IP Camera Input |
4ch |
|
IP Camera Supported List |
Hikvision, ACTI, Arecont, AXIS, Bosch, Brickcom, Canon, ONVIF, PANASONIC, Pelco, PSIA, SAMSUNG, SANYO, SONY, Vivotek and ZAVIO |
|
Video Output |
VGA / HDMI, up to 1080P |
|
Voice Intercom |
1-ch RCA(2.0Vp-p, 1kohm) input, 1-ch RCA(Linear, 1kohm) for output |
|
Display Split |
1/4 |
|
Resolution |
5MP / 3MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF |
|
Tour Display |
-- |
|
OSD |
Camera title, Time, Date |
|
Privacy Masking |
Support |
|
Compression |
H.264 |
|
Recording Resolution |
5MP / 3MP / 1080P / UXGA / 720P / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF |
|
Max Encoding Speed |
-- |
|
Recording Bit Rate |
Max. 25Mbps |
|
Recording Quality |
CBR, VBR |
|
Recording Mode |
Manual, Schedule(Regular(Continuous), MD(Video detection: Motion detection, Camera blank, Video loss), Alarm), Stop |
|
Recording Priority |
-- |
|
Recording Interval |
-- |
|
Trigger Events |
Recording, Alarm, Email, FTP, Buzzer & Screen tips |
|
Motion Detection |
Support |
|
Video Loss & Camera Blank |
Support |
|
Alarm in/out |
4/1 (Optional) |
|
Relay Output |
None (1-ch optional) |
|
Playback Channel |
4-ch@1080P |
|
Search Mode |
-- |
|
Playback Function |
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen |
|
Backup Mode |
-- |
|
Ethernet |
1 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interface |
|
Network Function |
TCP/IP protocol, UDP, RTP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, |
|
Max Remote Users |
-- |
|
Remote Operation |
Monitor, PTZ control, Playback, System setting, File download, Log information |
|
Hard Disk |
1 SATA Interfaces, Up to 3TB capacity for each disk |
|
eSATA |
-- |
|
HDD Management |
HDD quota and group management |
|
USB Interface |
1 x USB 2.0 and 1 x USB 3.0 |
|
RS485 |
-- |
|
RS232 |
-- |
|
Power Supply |
48V DC |
|
Power Consumption |
<= 10W (without hard disk and PoE) |
|
Working Environment |
Working temperature: -10 deg.C ~ +55 deg.C (+14 deg.F~ + 131 deg.F); Working humidity: 10 % ~ 90 % |
|
Dimension |
315 x 230 x 45mm (12.4 x9.1 x 1.8 inch) |
|
Weight |
2 Kg
|
|
